Graphite Anode Lithium Ion Battery GS-16 Modified artificial graphite

GS-16 Modified artificial graphite meet all power specifications
including high capacity (about 346.8mAh/g) and high first cycle
efficiency (about 95.9%). If you have a demand for GS-16 Modified artificial graphite powder, please feel free to send me an email for quotation.

(Graphite Anode Lithium Ion Battery GS-16 Modified artificial graphite)

Features of modified artificial graphite powder for li-ion battery anode：

1) High-energy density

2) Long-lifetime

3) Low expansion

4) Excellent processing performance

Application of graphite powder for li-ion battery anode：

Our Natural compound graphite powder is specially used in 3C digital, EV.

Storage of modified artificial graphite powder for li-ion battery anode：

1)
Modified artificial graphite powder for li-ion battery anode should be
stored in a dry, ventilated place where there is no other sources of
pollution (recommended: temperature ≤ 45 ° C, humidity ≤ 85%);

2)
Modified artificial graphite powder for li-ion battery anode should be
neatly stacked, and the production batch number, date and other signs
should be clearly identified;

3)Modified
artificial graphite powder for li-ion battery anode should be carefully
Handled during transportation to avoid the damage of the packaging;
products that leak out of the package must not be returned to the box.

(Graphite Anode Lithium Ion Battery GS-16 Modified artificial graphite)

Technical Data of graphite powder for li-ion battery anode：

No.	Name		Unit	Standard	Test method and instrument model
1	Particle size	D10	μm	7.0±2.0	Bt-9300s laser granulometer
		D50	μm	16.0±2.0
		D90	μm	28.0±3.0
2	TAP		g/cc	0.8±0.1	Bt-300 fully automatic vibration tester
3	SSA		m²/g	1.5±0.5	Nitrogen adsorption ratio table BET method
4	Purity		%	≥99.95	Muffle furnace Calcination
5	Compacted Density		%	1.68-1.72	Full battery design gram capacity / compaction density
	Capacity per Gram		mAh/g	360-365
6	True density		g/cc	≥2.22	Quantachrome true density meter
