High-energy-density, low-expansion, long-cycle graphite anode materials for use in 3C digital products series-TRSM2

This is a high-performance artificial graphite anode material specifically designed for 3C digital products

such as mobile phones, laptops, tablets, and wearable devices.

Through optimized crystal structure and surface modification processes, this product achieves high energy density while effectively reducing volume expansion during charge and discharge, significantly improving battery safety and structural stability.

The material exhibits excellent cycle life and stable electrochemical performance, meeting the comprehensive demands of 3C products for thinner and lighter designs, longer battery life, and higher reliability. This provides a reliable anode solution for next-generation high-end digital batteries.

Key technical indicators

number	name			unit	standard	Typical value	Testing methods and instrument models
1	particle size	Dmin		um	≥1.5	1.91	BT-9300S 型激光粒度仪
		D10		um	7.0±2.0	7.11
		D50		um	16.0±2.0	15.40
		D90		um	30.0±3.0	28.58
		Dmax		um	≤55	47.01
2	TAP			g/cc	1.1±0.1	1.10	BT-300 全自动振实测试仪
3	SSA			m2/g	1.5±0.5	1.57	氮吸附比表 BET 测试法
4	C			%	≥99.95	99.983	马弗炉煅烧法
5	Average compacted density			g/cc	1.70-1.80	1.75	克容量/压实密度
	Button reversible capacitance			mAh/g	355-365	358.3
6	true density			g/cc	≥2.22	2.261	康塔真密度仪
7	First-time effect of electricity			%	≥92%	93.1	CR2025（0.1C/0.1C）
8	Trace elements		Fe	ppm	≤15	8.21	ICP 溶解法
			Co	ppm	≤5	—
			Cu	ppm	≤5	—
			Ni	ppm	≤5	0.9
			Al	ppm	≤5	1.08

Usage suggestions

The recommended material design capacity is 355mAh/g, and the recommended average compaction density is 1.75-1.78g/cc. This product is suitable for aqueous systems.

Packaging & Transportation Storage Requirements:

1. Packaging Requirements:
   TRSM-2 artificial graphite should first be packed into 650mm×950mm plastic bags, sealed, and then placed in a cardboard box. The weight is 25 + 0.02kg/box, or packaged according to user requirements.
2. Transportation and Storage:

a. The product should be stored in a dry, ventilated place free from other sources of pollution (recommended: temperature ≤45℃, humidity ≤85%);
b. The product should be stacked neatly and cleanly, and the production batch number, production date, and other markings should be clearly identifiable;

c. Handle with care during transportation to avoid damaging the packaging; any product that spills out of the packaging must not be returned to the box.

d. Shelf life is 2 years at room temperature.
