High energy density, low expansion, long cycle life, and 3C-4C fast charging: graphite anode materials for EV power and power tools. series-TRSM1

TRSM-1 is a customized artificial graphite anode material designed for high-performance lithium-ion battery applications. Utilizing advanced graphitization technology and a refined particle structure design,

TRSM-1 achieves higher reversible specific capacity and stable initial coulombic efficiency while ensuring excellent rate performance. This product boasts advantages such as good consistency, high compaction density, and long cycle life, making it suitable for power batteries, energy storage batteries, and high-end consumer electronics.

Through flexible customized production solutions, TRSM-1 can be optimized in terms of particle size distribution, specific surface area, and electrochemical performance according to customer needs, contributing to an overall improvement in battery performance.

Key technical indicators

number	name			unit	standard	Typical value	Testing methods and instrument models
1	particle size	Dmin		um	≥1.0	2.11	BT-9300S 型激光粒度仪
		D10		um	6.0±2.0	7.02
		D50		um	14.0±2.0	14.40
		D90		um	26.0±3.0	23.48
		Dmax		um	≤50	40.21
2	TAP			g/cc	1.0±0.1	0.99	BT-300 全自动振实测试仪
3	SSA			m2/g	1.3±0.5	1.45	氮吸附比表 BET 测试法
4	C			%	≥99.95	99.975	马弗炉煅烧法
5	Average compacted density			g/cc	1.60-1.65	1.63	克容量/压实密度
	Button reversible capacitance			mAh/g	350-360	354.4
6	true density			g/cc	≥2.22	2.25	康塔真密度仪
7	First-time effect of electricity			%	≥93%	95.4	CR2025（0.1C/0.1C）
8	Trace elements		Fe	ppm	≤15	5.87	ICP 溶解法
			Co	ppm	≤5	0.57
			Cu	ppm	≤5	—
			Ni	ppm	≤5	0.99
			Al	ppm	≤5	—

Usage suggestions

The recommended material design capacity is 350-353 mAh/g, and the recommended average compaction density is 1.60-1.65 g/cc or below. This product is suitable for aqueous systems.

Packaging & Transportation Storage Requirements

TRSM-1 artificial graphite should first be packed into 650mm×950mm plastic bags, sealed, and then placed in a cardboard box, weighing 25 +0.02kg/box, or packaged according to user requirements.

Transportation and storage

a. The product should be stored in a dry, well-ventilated place free from other sources of contamination (recommended: temperature ≤45℃, humidity ≤85%);
b. Products should be stacked neatly and cleanly, and production batch numbers, production dates, and other markings should be clearly identifiable;
c. Handle with care during transportation to avoid damaging the packaging; any product spilling out of the packaging must not be returned to the box.

d. Shelf life is 2 years at room temperature.

Things to note

a) Ensure the negative electrode capacity per unit area is greater than or equal to the positive electrode capacity per unit area to avoid lithium plating during charging.

b) Ensure a good interface between the separator and the electrode.

c) The areal density and compaction density of the electrode will affect the rate, capacity, and performance.

d) This product is a secondary particulate carbonized product; a compaction density of 1.60 g/cc is recommended for optimal results.
